Swampfox Arrowhead LPVO – 1-6x24mm
|Dimensions||12.79 × 4.01 × 3.14 in|
|Objective Lens Diameter|
7.6mm (1x) – 3.9mm (6x)
3.39" (1x) – 3.54" (6x)
|FOV @ 100 Yards|
119.9' (1x) – 19.27' (6x)
|Travel Per Rotation|
60 Clicks / 30 MOA
|Max Elevation Adjustment|
|Max Windage Adjustment|
Fully Multi-Coated / Anti-fog / Hydrophobic
12 Position Illumination turret
BDC or MOA Glass Etched Illuminated
|Magnification Required for Reticle Accuracy|
|Fast Focus Diopter|
Yes, -2 to +2
Push/Pull Locking Turrets with Zero Reset
1,100 G Forces
The Swampfox Arrowhead LPVO series meets or exceeds every requirement for serious law enforcement and self-defense applications. Locking turrets require no tools to prevent unintentional adjustments. Arrowhead’s state-of-the-art optical design creates a brighter sight picture, a wider field of view, and excellent resolution. Choose from two Second Focal Plane reticles: Guerrilla Dot BDC Long and Guerrilla Dot MOA Long. In addition, Guerrilla Dot MIL Long and green reticle illumination are available in 1-10x Arrowheads only. If you are searching for an affordable LPVO that checks all the boxes needed for duty use, you just found it: the Swampfox Arrowhead.
SECOND FOCAL PLANE
Second Focal Plane construction provides a consistent reticle size at all magnifications. The result is an instant, familiar sight picture for unbeatable speed when it counts most– from close quarters distance out to 200 yards.
INCLUDED THROW LEVER
You need to be at maximum magnification to use the medium range holdovers, so Arrowhead’s included throw lever lets you slap your magnification to the max in a heartbeat. Arrowhead’s lever attaches directly via four bolts—there’s no ring to slip or loosen over time.
OCKING WINDAGE AND ELEVATION TURRETS
Arrowhead features push-pull locking turrets that require no tools and can be quickly used out in the field. Push the turrets towards the scope body to lock them in place. Pull them away from the scope body to adjust. Real simple, real tough. No more worries that a turret got “bumped” away from its zero when you weren’t looking. MOA reticles are paired with 0.5 MOA-per-click turrets. MIL reticles are paired with 0.1 MIL-per-click turrets.
BRIGHTEST DAY, DARKEST NIGHT
Arrowhead features dual LED emitters, making daylight bright etched reticle illumination possible at the highest settings. For those who must press on in the darkest night, the first two brightness settings are night vision compatible and cannot easily be seen by the naked eye at all. Arrowhead’s illumination knob features a tactile “OFF” notch between each of the 12 brightness settings.
SIGHT PICTURE SUPERIORITY
Great glass is just the start of what makes a truly superior sight picture. Arrowhead’s state-of-the-art optical engineering transmits an incredible amount of light through the lens, something you’ll notice as soon as you look through any Arrowhead—at any magnification.
GREAT GLASS IS JUST THE START
This is the best glass SwampFox makes, carefully infused with rare earth metals and polished to perfection. Only the most immaculate lenses are worthy to move on to the next step. The best anti-reflection, anti-fog, anti-scratch, and hydrophobic coatings are then applied and checked carefully before lens installation.
BETTER MATH, BETTER SCOPE
Arrowhead’s advanced optical engineering results in a wider field of view and superior overall brightness, without sacrificing eye relief or eye box characteristics, even at full magnification. You get it all with Arrowhead.
SPEED IS FINE, ACCURACY IS FINAL
Arrowhead’s fast focus eyepiece, excellent optical characteristics, and user-friendly controls make it a very “fast” scope for close quarters shooting. As range increases, more precision is required. Arrowhead’s turret tracking and reticle fidelity is excellent. From the flat, true 1x all the way out to 6x, 8x, or even 10x magnification, Arrowhead excels in a huge variety of real-world shooting situations.
ZERO RESET TURRETS
After sighting in your rifle it is easy to reset “zero” indication on the turrets using just a coin or wide screwdriver to release the outer turret and re-orient it. This very important feature can be adjusted in seconds without affecting the push/pull locking system at all.
READY WHEN YOU ARE
Arrowhead’s internal components are made of stronger materials and machined to the finest tolerances we can achieve. Even the main scope body is machined from a harder grade of aluminum. Toughness and precision are both increased at the same time, without sacrificing one goal to boost the other.
GUERRILLA DOT MOA LONG RETICLE
Not shooting 5.56 or .308? “Guerrilla Dot MOA Long” has you covered. A full 30 MOA of vertical holdover ladder is incorporated. Chrony your rifle, run your numbers through a ballistic calculator, and see how far you can stretch it. Can you take your 6.5 Grendel to 900 yards? Can you take your 6.5 Creedmoor to 1000 yards, with a 1-10x LPVO? Arrowhead’s MOA reticle is ready if you are.
GUERRILLA DOT MIL LONG RETICLE
Available only in the 1-10x Arrowhead, “Guerrilla Dot MIL Long” is our first partially illuminated LPVO reticle. Paired with 0.1 MIL-per-click locking turrets, this reticle offers 10 MIL of vertical holdover and a visually symmetrical presentation. Like our MOA reticles, Guerrilla Dot MIL Long is compatible with any caliber with the help of a quality ballistic calculator (our favorite is StrelokPro, which has all Arrowhead reticles built right into it). Shooters who prefer Milliradian math, this is the integrated reticle/turret system you’ve been asking for.
SwampFox designed and built Arrowhead for use in the most serious situations. Law enforcement patrol rifles, home defense carbines, defense of livestock from predators, hunting dangerous game, and more. We know that some of our customers will take Arrowhead into harm’s way. Arrowhead’s durability is our best statement of taking that responsibility extremely seriously.
Of course, like all Swampfox products, Arrowhead is backed by our 50,000 Round Guarantee.
